WCBX-B+G系列
生活污水处理装置

WCBx-B+G series domestic waste water treatment device consists of 4 water tight tank bodies and attachments.These 4 tank bodies respectively sewage tank, contact tank (1), contact tank (2), MBR membrane tank. Attach-ments: filter.oil-disposed device.filter tank.
After the black water in the way of nature inflow into the waste water tank being crushed completely will flowto first-stage contact oxidation tank to aerate by air pump, and contact with biofilm flowing filing. Of which,organic pollutant will, and generate CO2 and watero The gray water flow hair filter, the hairs is disposed andflow to the oil-delete device,and the oil will be disposed.and flow to MBR membrane tank.The The pollutantswill be digested again by activated sludge in MBR membrane tank and generate CO2 and water.The treatedsewage effluent will flow into filter tank by the process pump through the MBR membrane. The MBR membraneintercept the impurities in the water and be absorbed by filter tank. After the ultraviolet disinfection deviceeliminate the bacteria in water ,the clean water will be discharged overboard directly.
Precipitation of sludge in the MBR membrane tank is back to contact tank by air lift device, and cause a certaindegree of reflux ratio to improve the water quality, reduce the influent concentration, regulation and stability ofshock loading improve the biofilm activity, improve access to oxidation of organic loading rate counters.
